Relè 5V SPDT SYS-SH-105L - SANYOU
Accedi in modo che possiamo avvisarti di una risposta
Description
| Mounting Type | Through Hole |
|---|---|
| Coil Voltage | 5VDC |
| Contact Form | SPDT (1 Form C) |
| Contact Rating (Current) | 16A |
| Switching Voltage | 250VAC, 30VDC - Max |
| Coil Current | 108mA |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | PC Pin |
| Seal Rating | Sealed - Fully |
| Coil Insulation | - |
| Must Operate Voltage | 3.75 VDC |
| Must Release Voltage | 0.25 VDC |
| Operate Time | 20ms |
| Release Time | 8ms |
| Operating Temperature | -30°C ~ 70°C |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Relay Type | General Purpose |
| Coil Resistance | 48.5 Ohms |
