Relè 24V SPDT - AZ973-1C-24DC3 - ZETTLER
Accedi in modo che possiamo avvisarti di una risposta
Description
| Fornitore: | American Zettler |
| Codice componente: | AZ973-1C-24DC3 |
| RoHS: | Yes |
| HTS: | 8536490075 |
| COO: | CN |
| ECCN: | EAR99 |
| Supplier Standard Pack: | 40 |
| Relay Construction: | Non-Latching |
| Coil Current: | 68.57 mA |
| DC Coil Voltage: | 24 V |
| Contact Arrangement: | SPDT |
| Maximum Current Rating: | 40(NO)/30(NC) A |
| Mounting: | Bracket Mount |
| Operating Temperature: | -55 to 110 °C |
| Termination Style: | 0.25Quick Connect |
| Dimension: | 26.2 x 26.2 x 35.2 mm |
| Contact Form: | 1 Form C |
| Unit of Measure: | Per Each |
Features
Codice fornitore:
AZ973-1C-24DC3
Recensioni
Nessuna recensione trovata
